وزن	553.383 گرم
ابعاد	13.208 × 7.112 × 4.318 سانتیمتر
Range of product	9007
Series name	Heavy duty
Product or component type	Limit switch
Device short name	9007AW
Product specific applicatio	Precision
Body type	Plug-in
Mounting mode	Surface mounting
Operator profile	Plunger head
Material	Metal
Body material	Cast zinc
Operator material	Cast zinc
Fixing mode	By the body
Movement of operating head	Linear
Type of operator	Spring return push rod plunger steel with micrometer adjustment
Switch actuation	On end
Type of approach	1 direction, Vertical approach
Electrical connection	1-2 cables for screw-clamp terminals (AWG 22…AWG 12)
Cable entry	1 entry for 1/2″ – 14 NPT conforming to ANSI B1.20.1
Contacts type and compositi	NC-NO, switch function: SPDT-DB
Contact form	Form Z
Contact operation	Snap action
Contacts material	Silver contacts
Positive opening	Without
Terminals description ISO n	(3-4)NO(1-2)NC
Repeat accuracy	+/- 0.001 in
NEMA degree of protection	NEMA 1 conforming to Nema type 250, NEMA 12 conforming to Nema type 250, NEMA 13 conforming to Nema type 250, NEMA 2 conforming to Nema type 250, NEMA 4 conforming to Nema type 250
IP degree of protection	IP65 conforming to IEC 60529
Protective treatment	Epoxy powder coat
Unit type of package 1	PCE
Number of units in package	1
Package 1 height	4.318 CENTIMETER
Package 1 width	7.112 CENTIMETER
Package 1 length	13.208 CENTIMETER

9007AW46
