9007FTSB1
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
Limit switch, 9007, 600 VAC 12amp ft +options
جزئیات محصول
| وزن | 1.152 گرم |
|---|---|
| ابعاد | 9.398 × 16.256 × 7.62 سانتیمتر |
| Range of product |
9007 |
| Series name |
Severe duty foundry |
| Product or component type |
Limit switch |
| Device application |
Standard foundry switch |
| Device short name |
9007T/FT |
| Body type |
Fixed |
| Head type |
Rotary head |
| Base plate style |
Style B |
| Body material |
Cast zinc |
| Fixing mode |
By the body |
| Movement of operating head |
Rotary |
| Type of operator |
Spring return without operating lever |
| Switch actuation |
CW and CCWfrom left or right |
| Function available |
Not applicable |
| Electrical connection |
Screw-clamp terminals AWG 22…AWG 12 |
| Type of approach |
Lateral approach |
| Cable entry |
1 entry for 1/2" – 14 NPT conforming to ANSI B1.20.1 |
| Switch function |
SPDT-DB |
| Contact operation |
Snap action |
| Contact form |
Form Z |
| Contacts material |
Silver flashed copper |
| Positive opening |
Without |
| Contacts usage |
Not applicable |
| Repeat accuracy |
+/- 0.004 in linear travel of cam on 1.5 in lever arm |
| Contact code designation |
A600 ,AC (Ue = 120 V) Ie = 20 A conforming to NEMA rating designation ,AC (Ue = 240 V) Ie = 12.5 A conforming to NEMA rating designation ,AC (Ue = 480 V) Ie = 6.25 A conforming to NEMA rating designation ,AC (Ue = 600 V) Ie = 5 A conforming to NEMA rating designation ,DC (Ue = 120 V) Ie = 5 A conforming to NEMA rating designation ,DC (Ue = 250 V) Ie = 1 A conforming to NEMA rating designation ,DC (Ue = 600 V) Ie = 0.2 A conforming to NEMA rating designation ,P600 |
| Terminals description ISO n |
A (left side contact)B (right side contact) |
| Shock resistance |
30 gn for 9 ms conforming to IEC 60068-2-27 |
| Vibration resistance |
10 gn (f= 10-55 Hz) conforming to IEC 60068-2-6 |
| NEMA degree of protection |
NEMA 1 conforming to Nema type 250 ,NEMA 12 conforming to Nema type 250 ,NEMA 13 conforming to Nema type 250 ,NEMA 2 conforming to Nema type 250 ,NEMA 4 conforming to Nema type 250 |
| IP degree of protection |
IP67 conforming to IEC 60529 |
| Electrical shock protection |
Class 0 conforming to IEC 61140 |
| Protective treatment |
Corrosion resistant gray paint |
| Unit type of package 1 |
PCE |
| Number of units in package |
1 |
| Package 1 height |
7.62 CENTIMETER |
| Package 1 width |
16.256 CENTIMETER |
| Package 1 length |
9.398 CENTIMETER |
| Package 1 weight |
1.152 KILOGRAM |
