Limit switch, Limit switches XC Standard, XCKMR, reverse head stay put crossed rods, 2x(2 NC), slow, M20
جزئیات محصول
| وزن | 748 گرم |
|---|---|
| ابعاد | 19.6 × 7.7 × 8.9 سانتیمتر |
| Range of product |
OsiSense XC |
| Series name |
Special format |
| Product or component type |
Limit switch |
| Product specific applicatio |
For hoisting and mechanical handling applications |
| Device short name |
XCKMR |
| Body type |
Fixed |
| Head type |
Rotary head |
| Material |
Metal |
| Head material |
Zamak |
| Fixing mode |
By the body |
| Movement of operating head |
Rotary |
| Type of operator |
L = 200 mm ,Stay put crossed rods lever metal square rod 6 mm |
| Type of approach |
2 directions ,Lateral approach |
| Contacts type and compositi |
2 x (1 NC + 1 NO) |
| Body material |
Zamak |
| Contact operation |
break before make ,Slow-break |
| Cable entry |
3 entries tapped for M20 x 1.5 cable gland ,cable outer diameter: 7-13 mm |
| Electrical connection |
clamping capacity: 1 x 0.5…2 x 2.5 mm² ,Screw-clamp terminals |
| Contact block per direction |
2 per direction |
| Switch actuation |
By any moving part |
| Positive opening |
Without |
| Contacts insulation form |
Zb |
| Contact code designation |
A300 ,AC-15 (Ue = 240 V) ,DC-13 (Ue = 125 V) ,Ie = 0.55 A conforming to IEC 60947-5-1 appendix A ,Ie = 3 A ,Ithe = 10 A conforming to IEC 60947-5-1 appendix A ,Q150 |
| Resistance across terminals |
25 MOhm conforming to IEC 60255-7 category 3 |
| Terminals description ISO n |
(21-22)NC(13-14)NO |
| Shock resistance |
50 gn conforming to IEC 60068-2-27 |
| Vibration resistance |
25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| IK degree of protection |
IK07 conforming to IEC 62262 |
| IP degree of protection |
IP66 conforming to IEC 60529 |
| Electrical shock protection |
Class I conforming to IEC 60536 |
| Protective treatment |
TC |
| Product certifications |
CSACCCCEUL |
| Standards |
CSA C22.2 No 14UL 508IEC 60947-5-1 |
| Unit type of package 1 |
PCE |
| Package 1 height |
8.9 CENTIMETER |
| Package 1 width |
7.7 CENTIMETER |
| Package 1 length |
19.6 CENTIMETER |
| Package 1 weight |
748 GRAM |
| Unit type of package 2 |
S02 |
| Package 2 height |
15 CENTIMETER |
| Package 2 width |
30 CENTIMETER |
| Package 2 length |
40 CENTIMETER |
| Package 2 weight |
4.988 KILOGRAM |
| Unit type of package 3 |
PAL |
| Number of units in package |
96 |
| Package 3 height |
70 CENTIMETER |
| Package 3 width |
60 CENTIMETER |
| Package 3 length |
80 CENTIMETER |
| Package 3 weight |
76.128 KILOGRAM |
