XCKS133H29

شناسه محصول: TM-SLS-CR-X-XCKS133H29

برای دریافت مشاوره با ما در ارتباط باشید.

ارسال سریع

با پست پیشتاز

پشتیبانی ۲۴ ساعته

و ۷ روز هفته

تضمین کیفیت

و تضمین اصالت

رضایت مشتریان

افتخار ماست

توضیحات

Limit switch, Limit switches XC Standard, XCKS steel roller lever 1 NC and 1 NO

جزئیات محصول

وزن 190 گرم
ابعاد 13.3 × 9.5 × 4.3 سانتیمتر
Range of product

Telemecanique Limit switches XC Standard

Series name

Standard format

Product or component type

Limit switch

Device short name

XCKS

Sensor design

Form A conforming to CENELEC EN 50041

Body type

Fixed

Head type

Rotary head

Material

Plastic

Body material

Plastic

Head material

Plastic

Fixing mode

By the body

Movement of operating head

Rotary

Type of operator

Spring return roller lever steel

Type of approach

1 or 2 programmable direction

,

Lateral approach

Cable entry

1 entry tapped for M20 x 1.5 cable gland

,

cable outer diameter: 7-13 mm

Contacts type and compositi

1 NC + 1 NO

Contact operation

Snap action

Switch actuation

By 30° cam

Electrical connection

clamping capacity: 1 x 0.34…2 x 1.5 mm²

,

Screw-clamp terminals

Contacts insulation form

Zb

Positive opening

With

Contact code designation

A300

,

AC-15 (Ue = 240 V)

,

DC-13 (Ue = 250 V)

,

Ie = 0.27 A conforming to IEC 60947-5-1 appendix A

,

Ie = 3 A conforming to IEC 60947-5-1 appendix A

,

Q300

Resistance across terminals

25 MOhm conforming to IEC 60255-7 category 3

Terminals description ISO n

(21-22)NC(13-14)NO

Shock resistance

40 gn for 11 ms conforming to IEC 60068-2-27

Vibration resistance

25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6

IP degree of protection

IP66 conforming to IEC 60529

,

IP67 conforming to IEC 60529

IK degree of protection

IK05 conforming to IEC 62262

Electrical shock protection

Class II conforming to IEC 61140

,

class II conforming to NF C 20-030

Overvoltage category

Class II conforming to IEC 61140

,

class II conforming to NF C 20-030

Protective treatment

TC

Product certifications

CSACCCUL

Standards

CSA C22.2 No 14CENELEC EN 50041UL 508IEC 60947-5-1IEC 60204-1

Unit type of package 1

PCE

Package 1 height

4.3 CENTIMETER

Package 1 width

9.5 CENTIMETER

Package 1 length

13.3 CENTIMETER

Package 1 weight

190 GRAM

Unit type of package 2

S02

Package 2 height

15 CENTIMETER

Package 2 width

30 CENTIMETER

Package 2 length

40 CENTIMETER

Package 2 weight

4.598 KILOGRAM

Unit type of package 3

P06

Number of units in package

352

Package 3 height

70 CENTIMETER

Package 3 width

60 CENTIMETER

Package 3 length

80 CENTIMETER

Package 3 weight

66.88 KILOGRAM
