قیمت محصول
توضیحات
Limit switch, Limit switches XC Standard, XCLJ, red body steel, 1 NC + 2 NO, slow break contacts
جزئیات محصول
| وزن | 445 گرم |
|---|---|
| ابعاد | 4.1 × 6.8 × 12.6 سانتیمتر |
| Range of product |
Telemecanique Limit switches XC Standard |
| Series name |
Standard format |
| Product or component type |
Limit switch |
| Device short name |
XCLJ |
| Body type |
Fixed |
| Material |
Metal |
| Body material |
Zamak |
| Head material |
Zamak |
| Fixing mode |
By the body |
| Cable entry |
1 entry tapped for Pg 13.5 cable gland ,cable outer diameter: 9-12 mm |
| Electrical connection |
clamping capacity: 1 x 0.5…2 x 2.5 mm² ,Screw-clamp terminals |
| Contacts type and compositi |
1 NC + 2 NO |
| Contacts insulation form |
Zb |
| Contact operation |
Slow-break |
| Positive opening |
With |
| Resistance across terminals |
25 MOhm conforming to IEC 60255-7 category 3 |
| Terminals description ISO n |
(21-22)NC(33-34)NO(13-14)NO |
| Shock resistance |
50 gn for 11 ms conforming to IEC 60068-2-27 |
| Vibration resistance |
25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| IP degree of protection |
IP66 conforming to IEC 60529 |
| IK degree of protection |
IK07 conforming to IEC 62262 |
| Overvoltage category |
Class I conforming to IEC 61140 |
| Standards |
CENELEC EN 50041IEC 60947-5-1IEC 60204-1 |
| Unit type of package 1 |
PCE |
| Number of units in package |
1 |
| Package 1 height |
12.6 CENTIMETER |
| Package 1 width |
6.8 CENTIMETER |
| Package 1 length |
4.1 CENTIMETER |
| Package 1 weight |
445 GRAM |
