قیمت محصول
توضیحات
Safety switch, Telemecanique Safety switches XCS, with level, 2 NC + 1 NO, 1/2 NPT
جزئیات محصول
| وزن | 125 گرم |
|---|---|
| ابعاد | 3.8 × 20 × 3.2 سانتیمتر |
| Range of product |
Telemecanique Safety switches XCS |
| Product or component type |
Safety switch |
| Component name |
XCSPL |
| Design |
compact |
| Material |
Plastic |
| Head type |
Key operated turret head |
| Contacts type and compositi |
2 NC + 1 NO |
| Contact operation |
break before make ,Slow-break |
| Cable entry |
1 entry tapped for 1/2" NPT |
| Electrical connection |
clamping capacity: 1 x 0.34…2 x 0.75 mm² ,Terminal |
| Locking options description |
Without locking of actuator |
| Positive opening |
With NC contact |
| Insulation |
Double insulated |
| Operating rate |
10 cyc/mn for maximum durability |
| Safety level |
Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1 ,can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1 ,can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
| Body material |
PA (polyamide) |
| Head material |
PA (polyamide) |
| Safety reliability data |
B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Protective treatment |
TC |
| Product certifications |
CSAUL |
| Electrical shock protection |
Class II conforming to IEC 61140 |
| Standards |
CSA C22.2 No 14ISO 12100UL 508IEC 60947-5-1EN 1088/ISO 14119IEC 60204-1 |
| Vibration resistance |
5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance |
10 gn for 11 ms conforming to IEC 60068-2-27 |
| IP degree of protection |
IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
| Unit type of package 1 |
PCE |
| Number of units in package |
1 |
| Package 1 height |
3.2 CENTIMETER |
| Package 1 width |
20 CENTIMETER |
| Package 1 length |
3.8 CENTIMETER |
| Package 1 weight |
125 GRAM |
