XMAV25L2135
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
Pressure sensors XM, pressure switch XMA 25 bar, adjustable scale 2 thresholds, 1 C/O
جزئیات محصول
| وزن | 684 گرم |
|---|---|
| ابعاد | 17.2 × 11.4 × 6.2 سانتیمتر |
| Range of product |
Telemecanique Pressure sensors XM |
| Pressure sensor type |
Electromechanical pressure sensor |
| Pressure sensor name |
XMA |
| Contacts type and compositi |
1 C/O snap action |
| Controlled fluid |
Air (0-70 °C) ,Fresh water (0-70 °C) ,sea water (0-70 °C) |
| Fluid connection type |
G 1/4 (female) conforming to ISO 228 |
| Cable entry |
2 entries tapped for Pg 13.5 cable gland conforming to NF C 68-300 |
| Electrical connection |
clamping capacity: 1 x 1…2 x 2.5 mm² ,Screw-clamp terminals |
| Electrical circuit type |
Control circuit |
| Setting |
External |
| Colour of cover |
Transparent |
| Pressure switch type of ope |
Regulation between 2 thresholds |
| Scale type |
Fixed differential |
| Local display |
Without |
| Enclosure material |
PC impregnated with Lexan 123 |
| Pressure actuator |
Diaphragm |
| Materials in contact with f |
Canvas covered nitrilechromated zinc alloy |
| Operating position |
Any position |
| Operating rate |
10 CYCLE_PER_MINUTE |
| Standards |
CEIEC 60947-5-1 |
| Product certifications |
CSACCCUL |
| Protective treatment |
TC |
| Electrical shock protection |
Class I conforming to IEC 536 |
| IP degree of protection |
IP54 conforming to IEC 60529 |
| Unit type of package 1 |
PCE |
| Package 1 height |
6.2 CENTIMETER |
| Package 1 width |
11.4 CENTIMETER |
| Package 1 length |
17.2 CENTIMETER |
| Package 1 weight |
684 GRAM |
| Unit type of package 2 |
S03 |
| Number of units in package |
16 |
| Package 2 height |
30 CENTIMETER |
| Package 2 width |
30 CENTIMETER |
| Package 2 length |
40 CENTIMETER |
| Package 2 weight |
11.376 KILOGRAM |
