وزن	118 گرم
ابعاد	6 × 4 × 4 سانتیمتر
Range of product	Telemecanique Inductive proximity sensors XS
Series name	General purpose
Sensor type	Inductive proximity sensor
Sensor name	XS1
Device application	Mobile equipment
Sensor design	Cylindrical M30
Size	55 mm
Body type	Fixed
Type of output signal	Discrete
Wiring technique	3-wire
Discrete output function	1 NC
Detector flush mounting acc	Flush mountable
Discrete output type	PNP
Material	Metal
Electrical connection	4 pins, Male connector M12
[Us] rated supply voltage	12…24 V DC with reverse polarity protection
Output circuit type	DC
Switching capacity in mA	<= 200 mA with overload and short-circuit protection
IP degree of protection	IP65 conforming to IEC 60529, IP67 conforming to IEC 60529
Enclosure material	Nickel plated brass
Detection face	Frontal
Thread type	M30 x 1.5
Front material	PPS
Sensing range	8…15 mm
Differential travel	1…15 % of Sr
Status LED	Output state: 1 LED (yellow)
Switching frequency	<= 500 Hz
Voltage drop	<2 V (closed)
Current consumption	<= 10 mA no-load
Delay first up	10 MILLISECOND
Delay response	0.6 MILLISECOND
Marking	CE
Delay recovery	1.4 MILLISECOND
Product certifications	CSAULE2
Vibration resistance	25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Shock resistance	50 gn for 11 ms conforming to IEC 60068-2-27
Unit type of package 1	PCE
Number of units in package	1
Package 1 height	4 CENTIMETER
Package 1 width	4 CENTIMETER
Package 1 length	6 CENTIMETER
Package 1 weight	118 GRAM

XS130B3PBM12
