Inductive proximity sensors XS, inductive sensor XS2 M8, 24…240VAC/DC, cable
جزئیات محصول
| وزن | 41 گرم |
|---|---|
| ابعاد | 4.1 × 9.5 × 13.4 سانتیمتر |
| Range of product |
Telemecanique Inductive proximity sensors XS |
| Series name |
General purpose |
| Sensor type |
Inductive proximity sensor |
| Wiring configuration |
2-wire |
| Sensor name |
XS2 |
| Device application |
2-wire DC short-circuit protection |
| Sensor design |
Cylindrical M8 |
| Protection type |
Short-circuit protection multi voltage |
| Body type |
Fixed |
| Type of output signal |
Discrete |
| Wiring technique |
2-wire |
| Discrete output function |
1 NO |
| Detector flush mounting acc |
Non flush mountable |
| Material |
Metal |
| Electrical connection |
Cable |
| [Us] rated supply voltage |
24…210 V DC ,24…240 V AC 50/60 Hz |
| Output circuit type |
AC/DC |
| Switching capacity in mA |
5…200 mA AC/DC with overload and short-circuit protection |
| IP degree of protection |
IP67 |
| Enclosure material |
Nickel plated brass |
| Detection face |
Frontal |
| Thread type |
M8 x 1 |
| Front material |
PPS |
| Differential travel |
1…15 % of Sr |
| Cable composition |
2 x 0.34 mm² |
| Residual current |
1.5 mA open state |
| Status LED |
Output state: 1 LED (yellow) ,supply on: 1 LED (green) |
| Wire insulation material |
PVC |
| Switching frequency |
<= 25 Hz AC ,<= 4000 Hz DC |
| Voltage drop |
<5.5 V (closed state) |
| Delay first up |
70 MILLISECOND |
| Marking |
CE |
| Product certifications |
CSACCCUL |
| Vibration resistance |
25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
| Shock resistance |
50 gn for 11 ms conforming to IEC 60068-2-7 |
| Unit type of package 1 |
PCE |
| Package 1 height |
13.4 CENTIMETER |
| Package 1 width |
9.5 CENTIMETER |
| Package 1 length |
4.1 CENTIMETER |
| Package 1 weight |
41 GRAM |
| Unit type of package 2 |
S01 |
| Number of units in package |
11 |
| Package 2 height |
15 CENTIMETER |
| Package 2 width |
15 CENTIMETER |
| Package 2 length |
40 CENTIMETER |
| Package 2 weight |
631 GRAM |
