Inductive proximity sensors XS, inductive sensor XS5 M8, L33mm, stainless, Sn1.5 mm, 12…24 VDC, pigtail M8
جزئیات محصول
| وزن | 10 گرم |
|---|---|
| ابعاد | 2 × 1 × 8 سانتیمتر |
| Range of product |
Telemecanique Inductive proximity sensors XS |
| Series name |
General purpose |
| Sensor type |
Inductive proximity sensor |
| Product specific applicatio |
Not applicable |
| Sensor name |
XS5 |
| Sensor design |
Cylindrical M8 |
| Size |
33 mm |
| Body type |
Fixed |
| Enclosure material |
Stainless steel 303 |
| Type of output signal |
Discrete |
| Wiring technique |
3-wire |
| Discrete output function |
1 NC |
| Electrical connection |
3 pins ,Male connector M8 |
| Discrete output type |
PNP |
| [Us] rated supply voltage |
12…24 V DC with reverse polarity protection |
| IP degree of protection |
IP67 conforming to IEC 60529 |
| Switching capacity in mA |
<= 200 mA DC with overload and short-circuit protection |
| Detector flush mounting acc |
Flush mountable |
| Material |
Metal |
| Output circuit type |
DC |
| Detection face |
Frontal |
| ISO thread |
M8 x 1 |
| Front material |
PPS |
| Differential travel |
1…15 % of Sr |
| Wire insulation material |
PVC |
| Sensing range |
> 0…2.5 mm |
| Status LED |
Output state: 1 LED (yellow) |
| Switching frequency |
<= 5000 Hz |
| Current consumption |
<= 10 mA no-load |
