وزن	15 گرم
ابعاد	9.4 × 4.1 × 6.4 سانتیمتر
Range of product	Telemecanique Inductive proximity sensors XS
Series name	General purpose
Sensor type	Inductive proximity sensor
Sensor name	XS5
Device application	Not applicable
Sensor design	Cylindrical M8
Size	62 mm
Body type	Fixed
Type of output signal	Discrete
Wiring technique	3-wire
Discrete output function	1 NC
Detector flush mounting acc	Flush mountable
Discrete output type	NPN
Material	Stainless steel
Electrical connection	4 pins, Male connector M12
[Us] rated supply voltage	12…24 V DC with reverse polarity protection
Output circuit type	DC
Switching capacity in mA	<= 200 mA DC with overload and short-circuit protection
IP degree of protection	IP67 conforming to IEC 60529
Enclosure material	Stainless steel 303
Detection face	Frontal
Thread type	M8 x 1
Front material	PPS
Sensing range	> 0…2.5 mm
Differential travel	1…15 % of Sr
Status LED	Output state: 1 LED (yellow)
Switching frequency	<= 5000 Hz
Voltage drop	<2 V (closed)
Current consumption	<= 10 mA no-load
Delay first up	10 MILLISECOND
Delay response	0.1 MILLISECOND
Marking	CE
Delay recovery	0.1 MILLISECOND
Product certifications	CSAUL
Vibration resistance	25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Shock resistance	50 gn for 11 ms conforming to IEC 60068-2-27
Unit type of package 1	PCE
Number of units in package	1
Package 1 height	6.4 CENTIMETER
Package 1 width	4.1 CENTIMETER
Package 1 length	9.4 CENTIMETER
Package 1 weight	15 GRAM

XS508BLNBM12
