XS7D1A1DAL2
جدید
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
Inductive proximity sensors XS, inductive sensor XS7 80x80x26, PBT, Sn40mm, 12…24 VDC, cable 2 m
جزئیات محصول
| وزن | 364 گرم |
|---|---|
| ابعاد | 13.3 × 9.8 × 6.8 سانتیمتر |
| Range of product |
Telemecanique Inductive proximity sensors XS |
| Series name |
General purpose |
| Sensor type |
Inductive proximity sensor |
| Device application |
Not applicable |
| Sensor name |
XS7 |
| Sensor design |
Flat form 80 x 80 x 26 |
| Size |
26 mm |
| Body type |
Fixed |
| Enclosure material |
PBT |
| Type of output signal |
Discrete |
| Wiring technique |
2-wire |
| Discrete output function |
1 NO |
| Electrical connection |
Cable |
| [Us] rated supply voltage |
12…24 V DC with reverse polarity protection |
| IP degree of protection |
IP68 double insulation conforming to IEC 60529 |
| Switching capacity in mA |
1.5…100 mA DC with overload and short-circuit protection |
| Detector flush mounting acc |
Flush mountable |
| Material |
Plastic |
| Output circuit type |
DC |
| Detection face |
Frontal |
| Front material |
PBT |
| Differential travel |
1…15 % of Sr |
| Wire insulation material |
PVC |
| Cable composition |
2 x 0.34 mm² |
| Sensing range |
> 15…40 mm |
| Status LED |
Output state: 1 LED (yellow) |
| Switching frequency |
<= 100 Hz |
| Residual current |
0.5 mA open state |
| Voltage drop |
<4 V (closed) |
