XS8C2A1PDM12
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
جزئیات محصول
| Range of product |
Telemecanique Inductive proximity sensors XS |
|---|---|
| Series name |
Fail safe inductive sensor |
| Sensor type |
Inductive proximity sensor |
| Device application |
Mobile equipment |
| Sensor name |
XS8 |
| Sensor design |
Form 40 x 40 x 70 |
| Size |
70 mm |
| Body type |
Fixed |
| Enclosure material |
PBT |
| Type of output signal |
Discrete |
| Wiring technique |
3-wire |
| Discrete output function |
1 NO + 1 NC |
| Electrical connection |
4 pins ,Male connector M12 |
| Discrete output type |
PNP |
| [Us] rated supply voltage |
12…48 V DC with reverse polarity protection |
| IP degree of protection |
IP65 conforming to IEC 60529 ,IP67 conforming to IEC 60529 ,IP69K conforming to DIN 40050 |
| Switching capacity in mA |
<= 200 mA with overload and short-circuit protection |
| Detector flush mounting acc |
Flush mountable |
| Material |
Plastic |
| Output circuit type |
DC |
| Detection face |
5 positions turret head |
| Front material |
PBT |
| Safety level |
PL = d conforming to ISO 13849-1 ,SIL 2 conforming to IEC 61508 ,SILCL 2 conforming to IEC 62061 |
| Repeat accuracy |
<= 3% of Sr |
| Safety reliability data |
DC > 96 % with appropriate safety controller ,MTTFd = 2422 years ,PFHd = 47.1E-9 1/h with appropriate safety controller ,SFF = 98.9% |
| Differential travel |
3…15% of Sr |
| Sensing range |
> 15…40 mm |
| Status LED |
Output state: 1 LED (yellow) ,supply on: 1 LED (green) |
| Switching frequency |
<= 40 Hz |
