قیمت محصول
توضیحات
Inductive proximity sensors XS, Rot. monitoring, 40x40x15, Sn15mm, 6…6000c/mn, 24…240VAC/DC, 1/2″ 0.15 m
جزئیات محصول
| وزن | 90 گرم |
|---|---|
| ابعاد | 6.5 × 9.7 × 4.2 سانتیمتر |
| Range of product | Telemecanique Inductive proximity sensors XS |
| Series name | Application |
| Product or component type | Sensor |
| Sensor type | Inductive proximity sensor |
| Device application | Rotation monitoring |
| Sensor name | XS9 |
| Sensor design | Flat form 40 x 40 x 15 |
| Size | 15 mm |
| Body type | Fixed |
| Enclosure material | PBT |
| Type of output signal | Discrete |
| Wiring technique | 2-wire |
| Discrete output function | 1 NC |
| Electrical connection | 3 pins, Remote male connector 1/2″20 UNF |
| [Us] rated supply voltage | 24…240 V AC/DC 50/60 Hz |
| IP degree of protection | IP67 double insulation conforming to IEC 60529 |
| Switching capacity in mA | 5…200 mA DC, 5…300 mA AC |
| Detector flush mounting acc | Flush mountable |
| Material | Plastic |
| Output circuit type | AC/DC |
| Detection face | Frontal |
| Front material | PBT |
| Repeat accuracy | <= 3% of Sr |
| Differential travel | 3…15% of Fr |
| Wire insulation material | PVC |
| Sensing range | 8…15 mm |
| Status LED | Output state: 1 LED (yellow), supply on: 1 LED (green) |
| Switching frequency | <= 800 Hz |
| Residual current | 1.5 mA open state |
