XS9C4A2A2P20
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
Inductive proximity sensors XS, inductive sensor XS9 40x40x117, PBT, Sn25 mm, 12…24 VDC, terminals
جزئیات محصول
| وزن | 244 گرم |
|---|---|
| ابعاد | 14.5 × 5 × 5 سانتیمتر |
| Range of product |
Telemecanique Inductive proximity sensors XS |
| Series name |
General purpose |
| Sensor type |
Inductive proximity sensor |
| Device application |
Not applicable |
| Sensor name |
XS9 |
| Sensor design |
Form 40 x 40 x 117 |
| Size |
117 mm |
| Body type |
Fixed |
| Enclosure material |
PBT |
| Type of output signal |
Analogue |
| Wiring technique |
2-wire |
| Electrical connection |
4 x 1.5 mm² ,Screw-clamp terminals |
| Analogue output range |
4…20 mA |
| [Us] rated supply voltage |
12…24 V DC with reverse polarity protection |
| IP degree of protection |
IP65 conforming to IEC 60529 ,IP67 conforming to IEC 60529 ,IP69K conforming to DIN 40050 |
| Detector flush mounting acc |
Non flush mountable |
| Material |
Plastic |
| Output circuit type |
DC |
| Detection face |
5 positions turret head |
| Front material |
PBT |
| Linearity error |
<= 3% of Sr |
| Sensing range |
> 15…40 mm |
| Status LED |
Output state: 1 LED (yellow) |
| Output current drift |
5 PERCENTAGE |
| Current consumption |
0…4 mA no-load |
| Delay first up |
7.5 MILLISECOND |
| Marking |
CE |
| Delay response |
6 MILLISECOND |
| Delay recovery |
6 MILLISECOND |
