قیمت محصول
توضیحات
Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn40mm, 24…240 VAC, terminals
جزئیات محصول
| وزن | 505 گرم |
|---|---|
| ابعاد | 15.2 × 8.5 × 5.5 سانتیمتر |
| Range of product | Telemecanique Inductive proximity sensors XS |
| Series name | General purpose |
| Sensor type | Inductive proximity sensor |
| Sensor name | XSD |
| Sensor design | Form 80 x 80 x 40 |
| Size | 40 mm |
| Body type | Fixed |
| Enclosure material | Plastic |
| Type of output signal | Discrete |
| Wiring technique | 2-wire |
| Discrete output function | 1 NO or 1 NC programmable |
| Electrical connection | Screw-clamp terminals |
| [Us] rated supply voltage | 132 V AC |
| IP degree of protection | IP67 |
| Detector flush mounting acc | Non flush mountable |
| Material | Plastic |
| Output circuit type | AC |
| Detection face | 5 positions turret head |
| Front material | Plastic |
| Cable entry | 1 entry tapped for Pg 13.5 cable gland |
| Sensing range | > 40…60 mm |
| Switching frequency | <= 10 Hz |
| Product certifications | CCC |
| Unit type of package 1 | PCE |
| Number of units in package | 1 |
| Package 1 height | 5.5 CENTIMETER |
| Package 1 width | 8.5 CENTIMETER |
| Package 1 weight | 505 GRAM |
| Package 1 length | 15.2 CENTIMETER |
