وزن	275 گرم
ابعاد	13 × 12 × 4.5 سانتیمتر
Sensor type	Capacitive proximity sensor
Product specific applicatio	Detection of insulated or conductive materials
Sensor name	XT1
Sensor design	Cylindrical Ø 32 mm plain
Size	80 mm
Body type	Fixed
Detector flush mounting acc	Flush mountable
Material	Metal
Enclosure material	Nickel plated brass
Type of output signal	Discrete
Wiring technique	2-wire
Discrete output function	1 NO
Output circuit type	AC
Electrical connection	Cable
[Us] rated supply voltage	24…240 V AC 50…60 Hz
Delay response	30 MILLISECOND
IP degree of protection	IP67 conforming to IEC 60529, IP67 conforming to IEC 60947-5-2
Detection face	Frontal
Differential travel	< 0.2 x Sr
Repeat accuracy	< 0.15 x Sr
Wire insulation material	PVC
Status LED	Output state indication: 1 LED (yellow)
Residual current	5 mA open state
Switching frequency	<= 15 Hz
Voltage drop	<10 V (closed)
Current consumption	< 4 mA
Delay first up	200 MILLISECOND
Delay recovery	30 MILLISECOND
Marking	CE
Setting-up	Sensitivity by potentiometer
Standards	IEC 60947-5-2
Product certifications	cULus
Vibration resistance	10 gn amplitude = 1 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Shock resistance	30 gn for 11 ms conforming to IEC 60068-2-27
Unit type of package 1	PCE
Number of units in package	1
Package 1 height	4.5 CENTIMETER
Package 1 width	12 CENTIMETER
Package 1 length	13 CENTIMETER

XT132B1FAL2
