XUX0ARCTT16
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
Photoelectric sensors XU, XUX, multi, Sn 0…40 m, 24…240VAC/DC, terminals
جزئیات محصول
| وزن | 209 گرم |
|---|---|
| ابعاد | 4 × 9.5 × 13 سانتیمتر |
| Range of product |
Telemecanique Photoelectric sensors XU |
| Series name |
General purpose multimode |
| Electronic sensor type |
Photo-electric sensor |
| Sensor name |
XUX |
| Sensor design |
Compact 92 x 71 |
| Detection system |
Multimode |
| Material |
Plastic |
| Type of output signal |
Discrete |
| Supply circuit type |
AC/DC |
| Wiring technique |
5-wire |
| Discrete output function |
1 NO or 1 NC programmable |
| Electrical connection |
1 x 1.5 mm² or 1 x 0.75 mm² with adaptor ,Screw-clamp terminals |
| Product specific applicatio |
Not applicable |
| Emission |
Infrared diffuse ,infrared diffuse with background suppression ,infrared thru beam ,red polarised reflex |
| Enclosure material |
PBT |
| Lens material |
PMMA |
| Output type |
Relay |
| Cable entry |
1 entry for M16 x 1.5 cable gland ,cable outer diameter: 7-10 mm |
| Add on output |
<= 100 mA with overload and short-circuit protection ,With alarm output |
| [Us] rated supply voltage |
24…240 V AC/DC |
| Status LED |
1 LED (green) for supply ,1 LED (red) for instability ,1 LED (yellow) for output state |
| Switching capacity in mA |
0.5 A (cos φ = 0.4 for 0.5 million cycles at 1 operating cycle per second at 250 V) ,3 A (cos φ = 1 for 0.5 million cycles at 1 operating cycle per second at 250 V) |
| Switching frequency |
20 Hz |
| Maximum voltage drop |
<1.5 V (closed state) |
| Maximum power consumption i |
– |
| Delay first up |
200 MILLISECOND |
| Time delay range |
0.02…15 s monostable ,on-delay or off-delay (programmable) delay |
| Delay response |
25 MILLISECOND |
| Delay recovery |
25 MILLISECOND |
| Setting-up |
Self teaching |
