Photoelectric sensors XU, XUX, emitter, 24…240VAC/DC, terminals
جزئیات محصول
| وزن | 184 گرم |
|---|---|
| ابعاد | 13 × 9.5 × 4 سانتیمتر |
| Range of product |
Telemecanique Photoelectric sensors XU |
| Series name |
General purpose multimode |
| Electronic sensor type |
Photo-electric sensor transmitter |
| Sensor name |
XUX |
| Sensor design |
Compact 92 x 71 |
| Detection system |
Thru beam |
| Material |
Plastic |
| Supply circuit type |
AC/DC |
| Wiring technique |
3-wire |
| Electrical connection |
1 x 1.5 mm² or 1 x 0.75 mm² with adaptor ,Screw-clamp terminals |
| Product specific applicatio |
Not applicable |
| Emission |
infrared thru beam |
| Enclosure material |
PBT |
| Lens material |
PMMA |
| Cable entry |
1 entry for M16 x 1.5 cable gland ,cable outer diameter: 7-10 mm |
| Status LED |
1 LED (green) for supply on |
| [Us] rated supply voltage |
24…240 V AC/DC |
| Switching capacity in mA |
0.5 A (cos φ = 0.4 for 0.5 million cycles at 1 operating cycle per second at 250 V) ,3 A (cos φ = 1 for 0.5 million cycles at 1 operating cycle per second at 250 V) |
| Time delay range |
0.02…15 s monostable ,on-delay or off-delay (programmable) delay |
| Switching frequency |
20 Hz |
| Maximum voltage drop |
<1.5 V (closed state) |
| Current consumption |
20 mA no-load |
| Delay first up |
200 MILLISECOND |
