Photoelectric sensors XU, XUY, diffuse, analog laser, Sn 85 mm, 12…24 VDC, M12
جزئیات محصول
| وزن | 46 گرم |
|---|---|
| ابعاد | 9.1 × 6 × 2.8 سانتیمتر |
| Range of product |
Telemecanique Photoelectric sensors XU |
| Series name |
Application material handling |
| Electronic sensor type |
Photo-electric sensor |
| Sensor name |
XUY |
| Sensor design |
Compact 50 x 50 |
| Detection system |
Diffuse |
| Material |
Plastic |
| Supply circuit type |
DC |
| Wiring technique |
4-wire |
| Analogue output range |
0…10 V |
| Electrical connection |
1 male connector M12 ,4 pins |
| Product specific applicatio |
Position control of robot armmeasuring thickness of mechanical parts |
| Emission |
pulsed ,Red laser ,wavelength: 650 nm – class 1 conforming to IEC 825-1 |
| Enclosure material |
ABS ,anti-shock |
| Spot diameter |
0.8 mm at 65 mm |
| Spot dimension |
Ø 0.8 mm at 65 mm |
| Status LED |
dirty: 1 LED (red) ,supply on: 1 LED (green) |
| [Us] rated supply voltage |
24 V DC with reverse polarity protection |
| Switching capacity in mA |
3 mA (overload and short-circuit protection) |
| Voltage drop |
<2.4 V (closed state) |
| Current consumption |
35 mA no-load |
| Delay response |
30 ms for output circuit |
| Setting-up |
Parametering by buttons |
| Vibration resistance |
7 gn ,amplitude = +/- 1.5 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
| Shock resistance |
30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
| IP degree of protection |
IP67 conforming to IEC 60529 |
| Unit type of package 1 |
PCE |
| Package 1 height |
2.8 CENTIMETER |
| Package 1 width |
6 CENTIMETER |
| Package 1 length |
9.1 CENTIMETER |
| Package 1 weight |
46 GRAM |
| Unit type of package 2 |
S01 |
| Number of units in package |
10 |
| Package 2 height |
15 CENTIMETER |
| Package 2 width |
15 CENTIMETER |
| Package 2 length |
40 CENTIMETER |
| Package 2 weight |
685 GRAM |
