قیمت محصول
توضیحات
Photoelectric sensors XU, XUY, BGS, laser, Sn 300 mm, 12…24 VDC, M8
جزئیات محصول
| وزن | 73 گرم |
|---|---|
| ابعاد | 12.8 × 7.4 × 3.4 سانتیمتر |
| Range of product |
Telemecanique Photoelectric sensors XU |
| Series name |
Application ,materials handling |
| Electronic sensor type |
Photo-electric sensor |
| Sensor name |
XUY |
| Sensor design |
Compact |
| Detection system |
Diffuse with background suppression |
| Material |
Plastic |
| Type of output signal |
Discrete |
| Supply circuit type |
DC |
| Wiring technique |
4-wire |
| Discrete output type |
PNP and NPN |
| Discrete output function |
1 NO or 1 NC programmable |
| Electrical connection |
1 male connector M8 ,4 pins |
| Product specific applicatio |
Control of levelmonitoring for crack on a componentdetection of components on a printed circuitmonitoring of small parts on production machinesuppression of a background |
| Emission |
pulsed ,Red laser ,wavelength: 675 nm – class 2 |
| Enclosure material |
Glass impregnated nylon |
| Lens material |
PMMA |
| Output type |
Solid state |
| Spot diameter |
0 mm manual adjustment |
| Status LED |
NC function: 1 LED (none) ,NO function: 1 LED (red) ,Output state: 1 LED (green) ,time delay active: 1 LED (red) |
| [Us] rated supply voltage |
12…24 V DC with reverse polarity protection |
| Switching capacity in mA |
100 mA (overload and short-circuit protection) |
| Voltage drop |
<2 V (closed state) |
| Current consumption |
35 mA |
| Delay response |
40 ms for output circuit depending on wiring |
| Maximum delay recovery |
– |
| Setting-up |
Manual adjustment of focusing |
| IP degree of protection |
IP65 conforming to IEC 60529 |
| Unit type of package 1 |
PCE |
| Package 1 height |
3.4 CENTIMETER |
| Package 1 width |
7.4 CENTIMETER |
| Package 1 length |
12.8 CENTIMETER |
| Package 1 weight |
73 GRAM |
| Unit type of package 2 |
S02 |
| Number of units in package |
35 |
| Package 2 height |
15 CENTIMETER |
| Package 2 width |
30 CENTIMETER |
| Package 2 length |
40 CENTIMETER |
| Package 2 weight |
2.86 KILOGRAM |
