XX918A1A1L2
ارسال سریع
با پست پیشتاز
پشتیبانی ۲۴ ساعته
و ۷ روز هفته
تضمین کیفیت
و تضمین اصالت
رضایت مشتریان
افتخار ماست
قیمت محصول
توضیحات
Ultrasonic sensors XX, ultrasonic sensor, 24 VDC 0 10 V +options
جزئیات محصول
| وزن | 1860 گرم |
|---|---|
| ابعاد | 12.7 × 9.525 × 3.97 سانتیمتر |
| Range of product |
Telemecanique Ultrasonic sensors XX |
| Sensor type |
Ultrasonic sensor |
| Sensor name |
XX9 |
| Sensor design |
Ø 18 mm |
| Material |
PBT (polybutylene terephthalate) |
| Type of output signal |
Analogue |
| Type of sensing window |
Fixed |
| Wiring technique |
4-wire |
| [Us] rated supply voltage |
15…24 V DC with reverse polarity protection |
| ISO thread |
M18 x 1 |
| Electrical connection |
2 m cable length ,Cable |
| Product specific applicatio |
Analog output |
| Enclosure material |
ULTEM |
| Front material |
Silicone |
| Analogue output range |
0…10 V inverse |
| Minimum size of detected ob |
Cylinder diameter 1.6 mm – up to 63.5 mm sensing distance |
| Current consumption |
<= 50 mA |
| Status LED |
output state: 2 LEDs (green/yellow) ,Setting-up assistance: 2 LEDs (green/yellow (flashing)) |
| Maximum switching capacity |
1 kOhm with overload and short-circuit protection |
| Delay response |
2.5 MILLISECOND |
| Delay recovery |
1000 MILLISECOND |
| IP degree of protection |
IP67 conforming to IEC 60529 |
| Marking |
CE |
| Standards |
IEC 60947-5-2 |
| Product certifications |
UL |
| NEMA degree of protection |
NEMA 4X (indoor use only) |
| Vibration resistance |
+/-1 mm conforming to IEC 60068-2-6 (f = 10-55 Hz) |
| Shock resistance |
30 gn in all 3 axes for 11 ms conforming to IEC 60068-2-27 |
| Unit type of package 1 |
PCE |
| Number of units in package |
1 |
| Package 1 height |
3.97 CENTIMETER |
| Package 1 width |
9.525 CENTIMETER |
| Package 1 length |
12.7 CENTIMETER |
| Package 1 weight |
1.86 KILOGRAM |
