Inductive proximity sensors XS, inductive sensor XSD, form D flat, screw clamp terminals
جزئیات محصول
| وزن | 497 گرم |
|---|---|
| ابعاد | 15 × 9 × 5.5 سانتیمتر |
| Range of product |
Telemecanique Inductive proximity sensors XS |
| Series name |
General purpose |
| Sensor type |
Inductive proximity sensor |
| Sensor name |
XSD |
| Sensor design |
Form 80 x 80 x 40 |
| Size |
40 mm |
| Body type |
Fixed |
| Enclosure material |
Plastic |
| Type of output signal |
Discrete |
| Wiring technique |
2-wire |
| Discrete output function |
1 NO or 1 NC programmable |
| Electrical connection |
Screw-clamp terminals |
| [Us] rated supply voltage |
12…240 V AC |
| IP degree of protection |
IP67 |
| Detector flush mounting acc |
Non flush mountable |
| Material |
Plastic |
| Output circuit type |
AC |
| Detection face |
5 positions turret head |
| Front material |
Plastic |
| Cable entry |
1 entry tapped for 1/2" NPT cable gland |
| Sensing range |
> 40…60 mm |
| Switching frequency |
<= 10 Hz |
| Product certifications |
CCC |
| Unit type of package 1 |
PCE |
| Package 1 height |
5.5 CENTIMETER |
| Package 1 width |
9 CENTIMETER |
| Package 1 weight |
497 GRAM |
| Package 1 length |
15 CENTIMETER |
| Unit type of package 2 |
S02 |
| Number of units in package |
11 |
| Package 2 height |
15 CENTIMETER |
| Package 2 width |
30 CENTIMETER |
| Package 2 length |
40 CENTIMETER |
| Package 2 weight |
5.925 KILOGRAM |
